CNC Flat Bed Lathe Machine CK6130S by Hoton – Quality Manufacturing Solutions

Hot New Products Milling Machine - CNC Flat Bed Lathe Machine CK6130S – Hoton

Short Description:

DESCRIPTION OF GOODS Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors. Either vertical or horizontal 4-station or 6-station tool post or gang tools can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy. Both chuck and tailstock are supplied with hydraulic or manual type. The surface of the bedways is supersonic frequency hardened and precision ground with a long service life. The spindle bore size is Ø 80...

Send email to us

Product Detail

Product Tags

Feedback (2)

We have our own sales team, design team, technical team, QC team and package team. We have strict quality control procedures for each process. Also, all of our workers are experienced in printing field for Turret Milling Machine , Lathe Cm6241 , Manual Shears , We have been in operation for more than 10 years. We are dedicated to quality products and consumer support. We invite you to visit our company for a personalized tour and advanced business guidance.

Hot New Products Milling Machine - CNC Flat Bed Lathe Machine CK6130S – Hoton Detail:

DESCRIPTION OF GOODS

Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors.
Either vertical or horizontal 4-station or 6-station tool post or gang tools can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy.
Both chuck and tailstock are supplied with hydraulic or manual type.
The surface of the bedways is supersonic frequency hardened and precision ground with a long service life.
The spindle bore size is Ø 80mm. The spindle system is high in the rigidity and accuracy.

SPECIFICATIONS:ITEMS	CK6130S	CK6136S	CK6140S
Over bed	Ø300mm(12")	Ø360mm(14")	Ø400mm(15.7")
Over carriage	Ø135/Ø100mm (Gang tools)	Ø100mm (Gang tools)	Ø225/Ø150mm (Gang tools)
Maximum turned length	500 mm	500/750/1000mm	500/750/1000mm
Max. turning length	460mm	450/700/950 mm	450/700/950 mm
Spindle nose	D4 or A2-5	C5	C6
Spindle bore	Ø38 or Ø43mm	Ø40mm	Ø52mm
Cone hole diameter and taper of spindle hole	MT.No.5 or 40° Taper	MT.No.5	MT.No.6
Steps of spindle speed(Manual)	Variable
Range of spindle speed	200~3500r/min	200~2800r/min
Rapid feed for Axis Z	10m/min
Rapid feed for Axis X	8 m/min
Max. travel of Axis Z	460mm(18")	490/740/990 mm
Max. travel of Axis X	165/260mm (Gang tools)	295mm (Gang tools)	235/295mm (Gang tools)
Min. input	0.001mm
Tool post stations	Gang tool post or power tool post	4-ways or 6-ways or gang tools
Tool cross section	16×16 mm	20×20 mm
External diameter	Ø50mm	Ø60mm
Taper of bore	MT.No.3	MT.No.4
Max. Traverse	130 mm	120 mm
X/Z motor torque	3.6/4.7Nm	3.6/4.7Nm
Power of main motor	3KW(4HP)	3.7KW(5HP)	3.7KW/5.5KW
Power of cooling pump	75W
Overall dimensions(L×W×H)	1500×945×1380mm	(1870,2120,2370)×1200×1415mm
Net weight	1100kg	1500,1700,1900kg	1600,1800,2000kg

Product detail pictures:
