China Supplier Horizontal Cnc Lathe - Universal Tool Milling Machine X8130A – Hoton Detail:

UNIVERSAL TOOL MILLING MACHINE X8130A

This machine is a versatile machine of better universality,extensively used for milling flat,inclined surfaces and slots on metal parts and is suitable for machining tolls,fixtrues and moulds as well as machine parts of complicated shapes in instruments and meters manufacturing jplants and machinery building works

SPECIFICATIONS:

MODEL	X8130A
Horizontal working surface	320x750mm
T slot no./width/distance	5 /14mm /60mm
Vertical working surface	225x830mm
T slot no./width/distance	2 /14mm /126mm
Max. longitudinal travel( by hand/power)	405/395mm
Max. vertical travel( by hand/power)	390/380mm
Max. cross travel	200mm
spindle taper bore	ISO40 7:24
Max. swivel of vertical milling head	±60°
Distance from axis of horizontal spindle to table surface (Min./Max.)	35/425mm
Distance from vertical table to guideway	188mm
Quill movement	80mm
Number of spindle speeds	12
Range of spindle speeds	40-1600r/min
Main drive motor power	2.2kw
Speed of Main drive motor	1430r/min
Overall dimension	1170x1210x1600mm
Net weight	1100kgs

Product detail pictures:
