FEATURES:
Double cylinders hydraulic punch & shear machine
Five independent stations for punch, shear, notching, section cut
Large punch table with multi-purpose bolster
Removable table block for overhang channel / joist flange punching applications
Universal die bolster, easy change punch holder fitted, punch adapters supplied
Angle, round & square solid monoblock crop station
Rear notching station, Low power inching and adjustable stroke at punch station
Centralized pressure lubrication system
Electric panel with overload protection elements and integrated controls
Safety movable foot pedal
Technical Parameters:
|
Model |
Q35Y-25 |
|
Punching Pressure (T) |
115 |
|
Max. cutting thickness of sheet plates (mm) |
25 |
|
Material strength (N/mm²) |
≤450 |
|
Angle of Shear (°) |
8° |
|
Flat bar shearing (T*W)(mm) |
25*330 16*600 |
|
Max. length of cylinder stroke (mm) |
80 |
|
Trips frequency (times/min) |
10-18 |
|
Depth of throat (mm) |
400 |
|
Max. punching diameter (mm) |
35 |
|
Motor power (KW) |
7.5 |
|
Overall dimensions (L*W*H)(mm) |
2355*960*2090 |
|
Weight(kg) |
4000 |
Types of profiled steel for shearing (If you want Joist or Channel, need special order)
|
Steel category |
Round Bar |
Square Bar |
Equal Angle |
T Bar |
I-iron |
Channel steel |
|||
|
90° Shearing |
45° Shearing |
90° Shearing |
45° Shearing |
||||||
|
Section view |
|||||||||
|
Q35Y-25 |
60 |
50*50 |
160*160*14 |
80*80*7 |
160*160*14 |
80*80*10 |
200*102*9 |
200*75*9 |
|
Product detail pictures:
