New Arrival China Cnc Lathe Tck500 - Radial Drilling Machine Z3032X10 Z3040X10 – Hoton Detail:
RADIAL ARM DRILLING MACHINE FEATURES:
The Radial Drilling Machine, It's construction designed elaborately, with pefect appearance and convenient maintenance.
The headstock radial arm and columns are clamped by manual clamping mechanisms.
It has feature of wide speed and feed range,compact operation key, reliable and enough rigidy.
The machine has a sample rigidity and power in drilling, counter boring, spot facing reaming,tapping, even boring when equiped with a special device. It is widely used in every department of machining medium and small sizes workpieces.
Parameter:
SPECIFICATIONS:
|
MODEL |
Z3032X10 | Z3040X10 |
| Max.drilling capacity (mm) |
32 |
40 |
| Distance spindle axis to column generating line (mm) |
200-1000 |
|
| Diameter of column (mm) | 240 | |
| Spindle taper | MT4 | |
| Spindle travel (mm) | 250 | |
| Spindle speeds range (r/min) | 71-1800 | |
| Spindle speeds series | 8 | |
| Range of Spindle feeds (mm/r) | 0.13-0.54 | |
| Spindle feeds | 4 | |
| Distance spindle nose to working surface of base (mm) | 264-1064 | |
| Dimension of worktable (mm) | 400X450X400 | |
| Dimension of base (mm) | 1500X740X160 | |
| Overall size (mm) | 1730X750X2360 | |
| Power of Main motor (kw) | 2.2 | |
| G.W/NW (kg) | 1600/1530 | |
| Packing dimension (cm) | 187X97X220 | |
