Quality Inspection for Blacksmith Power Forging Hammer - Knee-type Milling Machine XL6036 XL6136 – Hoton Detail:

MILLING MACHINE

rotating worktable milling machine

1.Driven by AC servo motor

2.Table automatic feed on X,Y,Z

3.Automatic rapid feed X,Y,Z

4.Rotary table can be ordered

SPECIFICATIONS:

SPECIFICATION	UNIT	XL6036	XL6036C	XL6036CL
Spindle taper	-	7:24 ISO50
Distance between spindle nose and table	mm	20-480	20-470
Distance from spindle axis to arm	mm	175
Spindle speed range	-	12steps 60~1800r.p.m
Table size	mm	1325X360		1600X360
Table travel(X/Y/Z)	mm	750/320/460	1100/320/450	1300/320/450
Table feed(X/Y/Z)	mm/min	30-750 / 20-500 / 15-375
Table rapid speed (X/Y/Z)	mm/min	1200/800/600
T-slots(NO:/width/pitch)	mm	3/18/70
Arm travel	mm	500
Main motor power	kw	5.5
Torque of X/Y/Z axis AC servo motor	N.m	10
Overall size	mm	1800X2100X1870	2245X2100X1870	2520X2100X1870
Net weight	kg	2450	2515	2560

Product detail pictures:
