Ordinary Discount Bead Bending Machine - CNC Turret Milling Machine XK6325C – Hoton Detail:

CNC TURRET MILLING MACHINE FEATURES:

This milling machine equipped with economic CNC system is three coordinate NC milling machine possessing

a widely universal performance and attachments in a great varity may perform procedures, such as milling,

boring and drilling etc in addition it may be applied for processing various kinds of jobs without jigs such as

cams profile boards and jigs with complex figuration etc.

STANDARD ACCESSORIES:.

1.Draw bar

2.Tool box and tools

3. Working lamp

4.Elector lubricating pump

5.Hung up control panel

6.Cooling system

7.Oil collecting plate

8.Plastic splashing guard

OPTIONAL ACCESSORIES:

1.Air draw bar

2.Machine vise

3.Universal clamping kits

4.Collets and chuck

FEATURES:

Item			Unit	XK6323A	XK6323B	XK6325	XK6325A	XK6325B	XK6325C	XK6325D	XK6330	XK6330A
Table size			mm	230*1067		254*1270					305*1370
				230*1246		254*1370					305*1500
T slots				3*16
Table loading			kg	200		280					350
X axis (table longitudinal move) travel			mm	550		750					800
				740		850					900
Y axis (Table cross move) travel			mm	300		400	380	380	400	400	360	360
Z axis (Quill move) travel			mm	127
X/Y/Z axis rapid feed			mm/min	5000
X/Y/Z axis servo motor			kw	1
Knee vertical travel			mm	380		400					410
Ram travel			mm	315		465					500
Distance from spindle to table			mm	0-380		0-400					0-410
Milling head	Spindle speed	Standard:16 steps	rpm	50HZ:60-4500/60HZ:80-5440
		Optional:Variable		65-4200							60-3750
	Spindle taper			Standard:R8/Optional:ISO40							ISO40
	Motor Power		HP	3							5
	Head rotating	Swiveling		90	90	90	90	90	90	90	90	90
		Tilting		90	90	90	90	90	90	90	90	90
CNC				KND/HD500/GSK
Package			cm	165190220		190200223					200200225
G.W.			kg	1200		1500			1700		1900
