OEM/ODM Supplier Grinder My1224 - CNC Universal Cylinder Grinding Machine MKE1420Hx500 – Hoton Detail:

Model	Unit	MKE1420HX500
External grinding diameters	mm	φ8～200
Internal grinding diameters	mm	Φ30～100
Center height	mm	135
Headstock spindle rotation speed	r/min	50HZ:25～380stepless
Distance between center	mm	500
Max.workpiece weight	kg	30
Grinding length External/Internal	mm	500/125
Max.wheel peripheral speed	m/s	35
External wheel size	mm	φ400x50xφ203
wheel spindle rotation speed	r/min	1670
Internal wheel spindle rotating-speed	r/min	14000
Headstock center	morse	NO.4
tailstock center	morse	NO.4
Total motor power	kw	10.825
Min.pulse amount in X-axis	mm	0.001
Min.pulse amount in Z-axis	mm	0.001
Longitudinal servo motor	kw	2.6(10NM)
Traverse servo motor	kw	2.6(10NM)
Machine overall dimension（LxWxH）	mm	3000x2000x2000
Machine weight	kg	3000

Working Accuracy
Roundness（O.D/I.D）		1.5/2.5μm（O.D/I.D）
Uniformity of dia.in longitudinal section（O.D/I.D）		5/8μm（O.D/I.D）
Surface roughness(O.D/I.D)		Ra0.32/0.63μm（O.D/I.D）
