OEM Manufacturer Bench Milling Drilling Machine - Shaper Machine BY60100C – Hoton Detail:

SHAPING MACHINE

1.The machine is used in a variety of cutting and forming flat surface, suitable for single and small batch production.

2.Bed and other key parts of tempering, vibration aging, super audio quenching heat treatment process, makes the machine more stable accuracy, longer service life.

3.The principal cutting movement and feed movement are the hydraulic transmission, stepless speed regulation, with hydraulic overload protection device, smooth rotation, little overrun, start and stop is flexible and reliable, rigidity, cutting force, high directional accuracy, low temperature, small thermal deformation and precision stability, and can apply to the work of a strong and continuous cutting.

4.The machine tool can achieve rapid horizontal and vertical movement, turret with automatic tool lifting mechanism, machine tool handles, easy to operate, high degree of automation

SPECIFICATIONS:

MODEL	BY60100C
Maximum cutting length(mmin)	1000
Cutting speed of ram(mm/min)	3-44
Distance from lower edge of ram to upper surface of table(mm)	80-400
Max.cutting force(N)	28000
Max.travel of tool head(mm)	160
Maximum size of tool shank(W×T)(mm)	30×45
Upper working surface of table(L×W)(mm)	1000×500
Width of central T-slot of table(mm)	22
Max.horizontal travel of table(mm)	800
Horizontal feed of table per recip rotating stroke of ram(stepless) (mm)	0.25-5
Main motor(kw)	7.5
Motor for rapid motion of table(kw)	0.75
Overall dimensions(L×W×H)(mm)	3615×1574×1760
N.W/G.W(kg)	4200/4350
