New Fashion Design for Bending Machine - Column Drilling Machine Z5025B Z5025 – Hoton Detail:

VERTICAL ROUND COLUMN DRILLING MACHINE FEATURES:

The main performance characteristics:

1.Change speed with gears and operate easily ,

2.High spindle speed and wide speed range,

3.Characteristic auto tool releasing device guarantees it is very easy to change tool ,

4.Equipped with coolant system and work lamp.

Application:

Ideal choice for single piece and small batch production mass, production for drilling ,counter boring, tapping screws, spot facing machining, etc.

Product main technical Specifications:

SPECIFICATIONS:

Model	UNIT	Z5025
Max. Drilling capacity	mm	26
Diameter of column	mm	100
Spindle travel	mm	150
Distance spindle axis to column generating line	mm	225
Max. spindle nose to table	mm	630
Max. spindle nose to base	mm	1670
Spindle taper		MT3
Spindle speeds range	r/min	105-2900
Spindle speeds series		8
Spindle feeds	mm/r	0.07 0.15 0.26 0.40
Dimension of worktable surface	mm	440
Table travel	mm	560
Dimension of base table	mm	690x500
Overall height	mm	1900
Spindle motor power	K w	1.1
Coolant motor	w	40
G.W/N.W	kg	300/290
Packing dimension	cm	70x56x182

Product detail pictures:
