Hydraulic Press & Radial Drilling Machine Z3040x13

New Delivery for Hydraulic Press Machine - Radial Drilling Machine Z3040x13 – Hoton

Short Description:

Specifications Z3040X13 China Radial Drilling Machine Price can be widely used in drilling, reaming, reaming, planing plane, tapping and other processing. Z3040X13 China Radial Drilling Machine Price with high quality and high performance. 1. Small size, reduce the area occupied. 2. The control system is concentrated in the spindle box, variable speed flexible, convenient, feed safety insurance. 3. The basic large-scale use of high-quality materials molding casting, after aging treatment, wi...

Send email to us

Product Detail

Product Tags

Feedback (2)

We can always satisfy our respected customers with our good quality, good price and good service due to we are more professional and more hard-working and do it in cost-effective way for Precision Drilling-Milling Machine , Combination 3-In-1 Sheet Metal Machine , Surface Grinder , we could solve our customer problems asap and do the profit for our customer. If you need good service and quality , pls choose us , thanks !

New Delivery for Hydraulic Press Machine - Radial Drilling Machine Z3040x13 – Hoton Detail:

Specifications

Z3040X13 China Radial Drilling Machine Price can be widely used in drilling, reaming, reaming, planing plane, tapping and other processing. Z3040X13 China Radial Drilling Machine Price with high quality and high performance.
1. Small size, reduce the area occupied.
2. The control system is concentrated in the spindle box, variable speed flexible, convenient, feed safety insurance.
3. The basic large-scale use of high-quality materials molding casting, after aging treatment, with high-precision machine tool processing, with high accuracy.
4. The guide surface are hardened, the spindle using nitriding treatment, to extend the service life.
5. Gear with BH carburizing technology to extend the service life.

SPECIFICATIONS	Z3040X13
Max. drilling dia.(mm)	Cast iron40 Steel32
Distance from spindle nose to table surface(mm)	320—1180
Spindle center to column generating distance(mm)	350—1300
Spindle travel (mm)	180
Spindle Cone	4
Range of spindle speeds(r.p.m)	75, 130, 240, 380, 660,1200
Spindle speed series	6
Spindle feeding range(r.p.m)	0.10—0.25
Spindle feeding step	3
Rocker rotary angle	±90°
Main motor power (kw)	2.2
Movements motor power(kw)	0.75
Weight(kg)	1800
Overall dimensions(mm)	1800x705x2200

Product detail pictures:
