Manufacturer for Lathe Machine - Universal Lathe CD6260B – Hoton Detail:

CDB SERIES LARGE SPINDLE HOLE PRECISION LATHE

Large spindle bore of 65mm
Main spindle dynamic balanced, and supported at 2 points with taper roller bearings of Harbinbrand
Outward appearance featuring large plains, making the machine more good-looking
Gapped bed ways, which are super-audio frequency hardened
All gears hardened and ground by Reishauer grinding machine
Leadscrew and feed rod interlocked, both with overload protection
Automatic feed stopper
Configuration variable totally according to orders:
Metric or inch system; Right or left hand wheel; Large plane type; Halogen lamp; Quick change tool past; DRO; T-slot compound; Chuck guard; Leadscrew hood; Rapid traverse motor; Electromagnetic brake; Forced lubrication system.

STANDARD ACCESSORIES

OPTIONAL ACCESSORIES

3-jaw chuckCenter$center sleeverWrenchedOil gunOperation manual

Steady rest

follow rest

4-jaw chuck

Face plate

Thread dial

Longitudinal touch stop

Live centerQuick change tool postTaper copy ruler4-position longitudinal touch stop

SPECIFICATIONS:

MODEL		CD6236B	CD6240B	CD6250B		CD6260B
CAPACITIES	Max. swing over bed (mm)	360	400	500		600
	Max. swing over cross slide(mm)	185	225	325mm		360
	Center distance (mm)	1000, 1500, 2000mm
	Max swing in gap (mm)	490	530		630	730
	Valid length of gap	260mm
	Bed width	330mm
HEADSTOCK	Spindle hole	65mm
	Spindle nose	ISO-C6 or ISO-D6
	Spindle taper	Metric 70mm
	Spindle speeds (Number)	22-1800rpm (15 steps)
FEEDS	Metric threads range (Kinds)	0.5-28mm (66kinds)
	Inch Threads range (Kinds)	1-56 /inch(66kinds)
	Module threads range (Kinds)	0.5-3.5mm (33kinds)
	Diametral threads range (Kinds)	8-56 DP(33kinds)
	Longitudinal fees range (Kinds)	0.072-4.038mm/rev(0.0027-0.15 inch/rev) (66kinds)
	Cross feeds range (Kinds)	0.036-2.019mm/rev(0.0013-0.075 inch/rev) (66kinds)
	Rapid traveling speed of carriage	5m/min (16.4ft/min)
	Leadscrew size: Diameter/Pitch	35mm/6mm
CARRIAGE	Cross slide travel	300mm
	Compound rest travel	130mm
	Cross-section size of toolshank	20*20mm	25*20mm			25*25mm
TAILSTOCK	Taper of tailstock sleeve	Morse No.5
	Diameter of tailstock sleeve	65mm
	Travel of tailstock sleeve	120mm
MOTOR	Main drive motor	4.0kw or 5.5kw or 7.5kw				7.5kw
	Coolant pump motor	0.125kw
	Rapid traverse motor	0.12kw
Packing Size (LWH) (mm)
Center Distance 1000mm		242011501800
1500mm		292011501800
2000mm		346011501800
