Hot sale Slotting Machine - CNC Flat Bed Lathe Machine CK6140ZX – Hoton Detail:

PRODUCT FEATURES:

Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors.
Either vertical or horizontal 4-station or 6-station tool post or gang tools can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy.
Both chuck and tailstock are supplied with hydraulic or manual type.
The surface of the bedways is supersonic frequency hardened and precision ground with a long service life.
The spindle bore size is Ø 80mm. The spindle system is high in the rigidity and accuracy.

SPECIFICATIONS:

ITEMS	CK6140ZX	CK6146ZX	CK6150ZX
Over bed	Ø400mm	Ø460mm	Ø500mm
Over carriage	Ø210/Ø165mm (Gang tools)	Ø240/Ø205mm (Gang tools)	Ø280/Ø245mm (Gang tools)
Maximum turned length	750/1000/1500mm
Max. turning length	600/850/1350 mm
Spindle nose	D8
Spindle bore	Ø80mm
Cone hole diameter and taper of spindle hole	MT.No7
Steps of spindle speed (Manual)	Variable
Range of spindle speed	100~2000r/min
Rapid feed for Axis Z	10m/min
Rapid feed for Axis X	8 m/min
Max. travel of Axis Z	710/960/1460 mm
Max. travel of Axis X	250/330mm(Gang tools)
Min. input	0.001mm
Tool post stations	4-ways or 6-ways or gang tools
Tool cross section	25×25 mm
External diameter	Ø75mm
Taper of bore	MT.No.4	MT.No.5
Max. Traverse	130mm
Power of main motor	5.5KW(Extra 7.5KW)
Power of cooling pump	75W
Overall dimensions(L×W×H)	2060/2310/2790×1180×1500mm
Net weight	2100,2250,2800Kg	2200,2350,2900kg
