High Performance Bench Top Metal Lathe - Universal Lathe GH1340W – Hoton Detail:

GAP BED LATHE MACHINE FEATURES:
1.Super audio quenched and grinded bed ways;
2. 12 steps of spindle speeds
3. The main motor power is 2.4 kw
4. Foot brake can give rapid braking
5. Scram button equipped on the lathe
6. Spindle can be jogged to rotate, it is facilitate to shift gears, load or unload the workpieces.
7. Specially designed chip pan can be easier to remove the chips.
8. The lathe has safety switch to break power automatically when changing gears or belts.
FEATURES:

SPECIFICATIONS	MODEL		GH-1340W	GH-1440W
General Capacity	Wax.Swing over bed	mm	330	356
	Max.Swing over cross slide	mm	185	210
	Max.Swing over gap	mm	480	506
	Bed Width	mm	260
	Max.Distance between centers	mm	1000
Spindle	Taper of spindle bore		MT5
	Diameter of spindle bore	mm	40
	Steps of spindle speeds		12 steps
	Range of spindle speeds	r/min	40-1800
	spindle nose		D-4
Threading & Feeding	Metric thread range	mm	0.45-7.5(22kinds)
	Inch thread range	TPI	4-112(40kinds)
	Range of longitudinal feeds	mm	0.03-0.688(0.0011-0.0271inch/rev)
	Range of cross feeds	mm	0.015-0.220(0.0003-0.01inch/rev)
Leadscrew	Diameter of leadscrew	mm	22(7/8inch)
	Pitch thread of leadscrew	mm	4(8T.P.I.)
tailstock	Travel of tailstock quill	mm	120(4-3/4inch)
	Diameter of tailstock quill	mm	45(1-25/32inch)
	Taper of tailstock quill	mm	MT # 3
Power	Main motor power	kw	2.4(3HP)
	Coolant pump power	kw	0.04(0.055HP)
Output Size of Lathe(LWH)		mm	19007401150
Package Size of Lathe(LWH)		mm	19707601460
Net Weight		kg	945
Gross Weight		kg	1065

Product detail pictures:
