High Performance Bench Top Metal Lathe - Band Saw G5015 – Hoton Detail:

FEATURES OF METAL BAND SAWING MACHINE FROM HOTON MACHINERY:
1.adjustable horizontal/vertical metalworking band saw
2.has a vise that swivels up to 45 degree

MODEL		G5015	G5020	G5025
Motor		500w	1100w	1500w/750(380v)
Blade size(mm)		1735×13×0.9	2360×20×0.9	2725x27x0.9
Blade speed (m/min)		20-65	24,41,61,82(50HZ) 29,50,75,100 (60HZ)	72-36
Bow swivel degree		0°-60°	-45°~45°	45°-60°
capacity at 90°	Round	150mm	205mm	250mm
	square	150x180mm	215×205mm	240x240mm
	square	-	-	310x240mm
capacity at 60°	Round	70mm	-	120mm
	square	-	-	95x95mm
	square	-	-	120x95mm
capacity at 45°	Round	115mm	143mm	150mm
capacity at 45°	square	150×115mm	143x115 mm	130x130mm
N.W./G.W.(kgs)		78/90	190/227	330/380
