Free sample for Forging Hammer C41-25 - Bench Top Metal Lathe JY280V/JY280VF – Hoton Detail:

MINI LATHE MANUFACTURER FEATURES:

Most popular ,widely useful variable speed lathe

V-way bed is hardened and precision ground.
Super width bed way gets more capacity.
Spindle is supported by precision taper roller bearing

T-slotted cross slide

Power longitudinal feed allows threading

Adjustable gids for slideways

Top design of gearbox gets more function

Tailstock may be off set for turning tapers
Geared mill head gets more torque.
Equipped with high quality belt and control board
Tolerance test certificate, test flow chart included.

SPECIFICATIONS:

MODEL	JY280V-F
Distance between centers	700mm
Swing over bed	280mm
Swing over cross slide	165mm
Taper of spindle bore	MT4
Spindle bore	26mm
Number of spindle speeds	6/variable speed
Range of spindle speeds	125-2000/50-2000rpm
Range of cross feeds	0.02 -0.28mm /r
Range of longitudinal feeds	0.07 -0.40mm /r
Range of inch threads	8-56T.P.I
Range of metric threads	0.2 -3.5mm
Top slide travel	50mm
Cross slide travel	140mm
Tailstock quill travel	80mm
Taper of tailstock quill	MT2
Motor	0.75/1.1KW
Packing size	1400 × 700 × 680mm
Net weight	210kg / 230kg

STANDARD ACCESSORIES :

OPTIONAL ACCESSORIES

3-jaw chuck

Dead centers

Reductions sleeve

Change gears

Oil gun

Some tools

Steady rest

Follow rest

Face plate

4 jaw chuck

Live centers

Lathe tool

Stand base

Thread chasing dial

Lead screw cover

Tool post cover

Side brake
