Factory Cheap Motorized Bending Machine - Universal Lathe C6246V/1000 C6246V/1500 – Hoton
Factory Cheap Motorized Bending Machine - Universal Lathe C6246V/1000 C6246V/1500 – Hoton Detail:
METAL LATHE MACHINE FEATURES:
The guide way and all gears in the head stock are hardened and precision ground.
The spindle system is high rigidity and accuracy.
The machines have powerful head stock gear train, high rotating accuracy and smooth running with low noise.
An overload safety device is provided on the apron.
Pedal or electromagnetic braking device.
Tolerance test certificate, test flow chart included
| STANDARD ACCESSORIES: | OPTIONAL ACCESSORIES |
| 3 jaw chuckSleeve and centerOil gun | 4 jaw chuck and adapterSteady restFollow restDriving plateFace plateWorking lightFoot brake system
Coolant system |
SPECIFICATIONS:
|
SPECIFICATION |
MODEL |
|||||||||||
|
C6241×1000 |
C6241V×1500 |
C6246×2000 |
C6246V×1000 |
C6246V×1500 |
C6246V×2000 |
|||||||
|
Capacity |
||||||||||||
|
Swing over bed |
410 |
460 |
||||||||||
|
Swing over cross slide |
220 |
270 |
||||||||||
|
Swing in gap diameter |
640 |
690 |
||||||||||
|
Distance between centers |
1000 |
1500 |
2000 |
1000 |
1500 |
2000 |
||||||
|
Valid length of gap |
165mm |
|||||||||||
|
Width of bed |
300mm |
|||||||||||
|
Headstock |
||||||||||||
|
Spindle nose |
D1-6 |
|||||||||||
|
Spindle bore |
58mm |
|||||||||||
|
Taper of spindle bore |
No.6 Morse |
|||||||||||
|
Range of spindle speed |
12 changes, 25～2000r/min |
|||||||||||
|
Feeds and threads |
||||||||||||
|
Compound rest travel |
128mm |
|||||||||||
|
Cross slide travel |
285mm |
|||||||||||
|
Max.section of tool |
25×25mm |
|||||||||||
|
Lead screw thread |
6mm or 4T.P.I. |
|||||||||||
|
Longitudinal feeds range |
42 kinds, 0.031～1.7mm/rev(0.0011"～0.0633"/rev) |
|||||||||||
|
Cross feeds range |
42 kinds, 0.014～0.784mm/rev(0.00033"～0.01837"/rev) |
|||||||||||
|
Threads metric pitches |
41 kinds, 0.1～14mm |
|||||||||||
|
Threads imperial pitches |
60 kinds, 2～112T.P.I. |
|||||||||||
|
Threads diametral pitches |
50 kinds, 4～112DP |
|||||||||||
|
Threads module pitches |
34 kinds, 0.1～7MP |
|||||||||||
|
Tailstock |
||||||||||||
|
Quill diameter |
60mm |
|||||||||||
|
Quill travel |
130mm |
|||||||||||
|
Quill taper |
No.4 Morse |
|||||||||||
|
Motor |
||||||||||||
|
Main motor power |
5.5kW(7.5HP) 3PH |
|||||||||||
|
Coolant pump power |
0.1kW(1/8HP) 3PH |
|||||||||||
|
Dimension and weight |
||||||||||||
|
Overall dimension(L×W×H) |
220×108×134 |
275×108×13 |
325×108×134 |
220×108×137 |
275×108×137 |
325×108×137 |
||||||
|
Packing size(L×W×H) |
225×112×162 |
280×112×156 |
330×113×156 |
225×112×162 |
280×112×156 |
330×113×156 |
||||||
|
Net weight |
1580kg |
1745kg |
1900kg |
1645kg |
1810kg |
1965kg |
||||||
|
Gross weight |
1845kg |
2050kg |
2230kg |
1910kg |
2115kg |
2295kg |
||||||
Product detail pictures:
