Discountable price Mechanical Cutting Shears - Heavy Duty Lathe CW61180L CW61190L – Hoton Detail:

HEAVY DUTY LATHE MACHINE FEATURES:

These lathes can perform to turn end-faces,cylindricl surfaces and internal holes of various parts as well as metric,inch,module and pitch threads.The top slides can be operated individually by power for cutting short taper surface. Long taper surface can be turned automatically through the compound movement combining longitudinal feed with the top slide feed,moreover,the machines may be used for drilling,boring and trepanning.
They are characteristics of power,high spindle speed,high rigidity.The various ferrous and non-ferrous metals parts may be turned through the heavy cutting by carbon alloy tools.

SPECIFICATIONS:

SPECIFICATIONS		MODEL
		CW61125L	CW61140L	CW61160L	CW61180L	CW61190L
Capacity	Max.swing diameter over bed (mm)	1250	1400	1600	1800	1900
	Max.swing diameter over crossslide (mm)	880	1030	1230	1400	1500
	Width of bed (mm)	1100
	Max.length of workpiece (mm)	1000-8000
Spindle	Spindle nose	A15
	Sindle bore diameter	130mm
	Taper of spindle bore	Metric 140#
	Range of spindle speed	3.15-315r/min 21kinds
Feeding	Longitudinal feeds range	0.12-12mm/r 56kinds
	Transversal feeds range	0.05-6mm/r 56 kinds
	Metric thread range	1-120mm 44 kinds
	Inch thread range	3/8-28 31 kinds
	Module thread range	0.5-60mm 45 kinds
	Pitch thread range	1-56 25 kinds
Tailstock	Tailstock sleeve taper	Metric 80#
	Tailstock sleeve diameter	200mm
	Tailstock sleeve travel	260mm
Motor	Main motor power	30Kw
	Rapid motor power (kw)	1.5Kw
	Coolant pump power (kw)	0.125Kw

STAND ACCESSORIES

1. four-jaw chuck F 1250mm 2.CW61125L,CW61140L,CW61160L:steady rest F120--480mm(for more than 2m) CW61180L,CW61190L: steady rest F400--700mm(for more than 2m) 3. follow rest(for more than 2m) 4. Morse No.6 Center 5. Tools 6.Set-over screw

OPTIONAL ACCESSORIES

1. Metric chasing dial device2. Inch chasing dial device3. Inch leadscrew4. T-type toolpost
