8 Year Exporter Double Column Band Saw - Punch Press J23 series – Hoton Detail:

PUNCH PRESS MACHINE FEATURES:

J23 series general open back & Inclinable press

Adopts horizontally placed crankshaft.

Rigid rotated bond clutch.

Model		JC23-6.3	J23-10B	J23-16	J23-16B	J23-25A	JG23-35A
Capacity	kN	63	100	160	160	250	350
Nominal Force	mm	3	4	5	5	5	5
Slide Stroke	mm	35	60	55	70	80	100
SPM	min-1	170	145	125	125	60	53
Max. Die Height	mm	110	130	160	170	180	180
Die Height Adjustment	mm	30	35	45	45	70	75
Between Slide Center & Frame	mm	110	130	160	170	210	200
Bolster (FB×LR)	mm	200×310	240×360	300×450	320×480	400×600	380×610
Bolster Opening (Up Hole Dia.×Dpth×Low Hole Dia.)	mm	Φ60	Φ120×20 ×Φ100	Φ100	Φ100	Φ120	Φ130
Bolster Thickness	mm	40	50	40	60	70	70
Bolster Opening (Dia.×FB×LR)	mm	Φ140×110×160	Φ130×90 ×180	Φ210×160 ×240	Φ210×160 ×240	Φ180×130 ×260	Φ180×130 ×290
Slide Area (FB×LR)	mm	120×140	150×170	180×200	180×200	210×250	210×250
Shank Hole (Dia.×Dpth)	mm	Φ30×55	Φ30×55	Φ40×60	Φ40×60	Φ40×70	Φ40×60
Max. Inclined Angle	°	30°	25°	25°	25°	25°	25°
Between Columns	mm	150	180	220	220	260	300
Motor Power	kW	0.75	1.1	1.5	1.5	2.2	3
Outline Size (FB×LR×H)	mm	780×610 ×1505	915×700 ×1690	1150×900 ×1910	1150×900 ×1910	1325×990 ×2140	1490×1080 ×2200
Net Weight	kg	360	600	1080	1080	1900	2440

Product detail pictures:
