2017 wholesale price Machine Center - CNC Slant Lathe Machine TCK50A – Hoton Detail:

Product main features:
Higher accuracy Taiwan linear guideways
Higher speed spindle unit,optional homemade spindle
Higher rigidity cast iron
Integrated automatic lubrication
One-piece casting slant bed cnc lathe

Model	Unit	TCK50A
Max.swing over bed	mm	560
Max.swing over cross slide	mm	260
Max.workpiece length	mm	350/500
Spindle unit	mm	200
The spindle nose(optional chuck)		A2-6
The spindle motor power	kw	7.5/11
Max.spindle speeds	rpm	3500
Spindle bore	mm	Φ66
Bar capacity	mm	55
The x/z axis screw specifications		3210/4010
The x axis limit stroke	mm	240
The z axis limit stroke	mm	400/540
The x axis motor torque	N.m	7.5/10
The z axis motor torque	N.m	7.5/10
X/z axis repeat position accuracy	mm	+/-0.003
Tool turret (optional)		100-8T/12T
Turret center height dimensions	mm	100
Hydraulic quill dia.	mm	70
Hydraulic quill taper		MT5
Hydraulic tailstock travel	mm	200/450
Machine dimensions(LWH)	mm	260018502000
N.W.	kg	4500
