China MR-13D Drill Bit Sharpener – Hoton Horizontal Shaper Machine

2017 Latest Design Horizontal Shaper Machine - MR-13D Drill Bit Sharpener – Hoton

Short Description:

Product Description 1.Grinding is accurate and rapid, easy operation with no skill to grind. 2.Economical price that greatly reduces the cost and improves the use effect. 3.With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life. 4.The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life. 5.Bearing shaft and locking unit. 6.The machine is set up with the function of adjusting a point (central po...

Send email to us

Product Detail

Product Tags

Feedback (2)

"Sincerity, Innovation, Rigorousness, and Efficiency" is the persistent conception of our firm to the long-term to develop together with consumers for mutual reciprocity and mutual advantage for Motorized Bending Machine , Cnc Lathe Cak6150 , Mini Milling Machine , We welcome customers, business associations and friends from all parts of the world to contact us and seek cooperation for mutual benefits.

2017 Latest Design Horizontal Shaper Machine - MR-13D Drill Bit Sharpener – Hoton Detail:

Product Description

1.Grinding is accurate and rapid, easy operation with no skill to grind.
2.Economical price that greatly reduces the cost and improves the use effect.
3.With diamond grinding wheel, it can be equipped directly with an accurate angle and long service life.
4.The electrically controlled and powerful DC motor: stable frequency, strong horsepower and long service life.
5.Bearing shaft and locking unit.
6.The machine is set up with the function of adjusting a point (central point) size, which can effectively coordinate with the material of drill hole and the rotation speed. It can control the quality precision and prolong the service life of the drill bit.

Specification

Model	MR-13D
Grinding Range	Φ2-Φ13(Φ15)
Point Angle	95°(90°)~135°
Power	AC220V
Motor	120W
Speed	4400rpm
Dimension	321819
Weight	10kg
Standard Equipment	Grinding wheel :CBN (for HSS)×1
	Eleven collets: Φ3,Φ4,Φ5,Φ6,Φ7,Φ8,Φ9,Φ10,Φ11,Φ12,Φ13
	Collet chuck:(Φ2-Φ14)×1
Option Equipment	Grinding wheel :SD (for Carbide)
	Collets: Φ2,Φ2.5,Φ3.5,Φ4.5,Φ5.5,Φ14,Φ15
	Collet chuck:Φ15

Product detail pictures:
